Project Description

Item No.: JD5

NO.1: Excellent mechanical T shape frame structure, main bottom frame was wholly

milled by German imported 6 meter planer type milling machine, which tolerance is

only less than 0.05mm.

NO.2: Feeding up gear protective cover, which protect the operator or engineer from

the risk  of hurt.

NO.3:Media feeding system of JADE T Series machines is able to fulfill different

demand of different material for customers.

NO.4: Multiple 3 phases constant heating system promotes ink absorption of material,

which makes printing clearer, dry faster and image stay for longer.

NO.5: Adopt the TAIWAN HIWIN rail; make sure the long use in printing and head

carrier moves steadily and quietly. The German IGUS chain has been certified with

its quality.

No. 6: JADE Printer with Konica Minolta 512I.JADE printer use BYHX system which

certified and strongly recommend by Konica Minolta.

JADE Factory Detail
In Mar.,2014,LOLY CO. LTD will completely move to another place of Guangzhou
Zengcheng district for expanding the business. JADE brand machine has its show
room and manafacturing line in LOLY company.
JADE JD5 3.2m Konica 512i printhead digital vinyl flex banner solvent printer/plotter/printing machine
Factory Team and Service Team
JADE JD5 3.2m Konica 512i printhead digital vinyl flex banner solvent printer/plotter/printing machine
JADE JD5 3.2m Konica 512i printhead digital vinyl flex banner solvent printer/plotter/printing machine
 JADE Printer exhibition:
JADE JD5 3.2m Konica 512i printhead digital vinyl flex banner solvent printer/plotter/printing machine
JADE JD5 3.2m Konica 512i printhead digital vinyl flex banner solvent printer/plotter/printing machine
Product Name JADE JD5 SOLVENT PRINTER
Maximum Print Width 3200mm (10.5ft)
Printing Resolution 480DPI (Physical)
Product Model 4H
KM512I-30PL Printhead       (4head) 480X360dpi 2pass 110sqm/h
480X540dpi 3pass 80sqm/h
480X720dpi 4pass 50sqm/h
Ink Type Low Solvent Ink
Color 4 Colors( C , M , Y , K )
Capacity 5L Per Main Tank of Each Color
Ink Supply System Low Ink Detector, Auto or Manual Ink Supply System
Media Width 3300mm (10.8ft)
Type Vinyl,Flex,Polyester,Back-lit Film, Window Film,etc
Media Feeding System Equipped (Max. Media Weight 120kg )
Auto Cleaning System Positive Pressure Cleaning Anti-clogged Flash Function &   Capping System
Heating &

Drying System

Equipped (Drying System Optional)
Clamp Equipped
Print Interface USB2.0
Printhead Height 2 to 4 mm Above Media Adjustable
RIP Software PhotoPRINT10.5 or Maintop V5.30
Input Power AC 220V ,50Hz
Operation Environment Temperature: 20~28℃ Humidity: 40%~60%
Machine Dimension L4,360x W790 x H1,170 mm; Net Weight: 700Kgs
Package Dimension Dismantle package:L4,820 x W1000 x H1050mm

Normal Package: L4,820 x W1000 x H1570mm;

Gross Weight: 820Kgs; Four units in one 20 feet container.

Packaging Details
standard wooden case
Delivery Time
within 5 working days after receive payment
